WATLOW Series 988 User’s Manual
4.31
Setup Menus, Chapter 4
Setup-Output
Silencing 4
Select silencing to inhibit alarm 4 on startup and to allow the opera-
tor to reset the alarm output, not the visual display.
• Silencing disables the alarm until the signal is between [A4LO] and
[A4HI].
[SIL4] This prompt appears only on controllers equipped with output 4
hardware for a relay (98_ _-_ _ _ _-_B_ _, 98_ _-_ _ _ _-_D_ _ ,
98_ _-_ _ _ _-_E_ _ or 98_ _-_ _ _ _-_K_ _) or switched dc (98_ _-_ _ _ _-_C_ _)
and with [`Ot4] set to [`AL4] or [AL4n].
Default
↓
[`OFF]
[``On]
[SIL4]
[SIL4]
Analog Output
Select which value to retransmit as the output 3 signal.
• [Prc1] retransmits the process 1 value.
• [StPt] retransmits the set point.
• [Prc2] retransmits the process 2 value. This prompt appears only if the
controller is equipped with input 2 hardware and if [`In2] is not set to
[``no] or [`Ei2].
• [``no] turns off retransmit function.
[Aout] This prompt appears only on controllers equipped with retransmit
hardware (98_ _-_ _ _ _-M_ _ _ or 98_ _-_ _ _ _-N_ _ _).
Default
↓
[Prc1]
[StPt]
[Prc2]
[``no]
[Aout]
[Aout]
[Aout]
[Aout]
˜
NOTE:
See
for
more information
on alarms.
[SIL4]
˜
NOTE:
See
for
more information
on retransmit.
[Aout]
