Watlow EZ-ZONE ® ST • 39 • Chapter 4 Setup Page
Chapter 4: Setup Pages
Control Module Setup Page Parameters
4
[``Ai]
[`Set]
Analog Input Menu
[```1]
[``Ai]
Analog Input 1 (to 2)
[`SEn] Sensor Type
[`Lin] Linearization
[`rt;L] RTD Leads
[Unit] Units
[`S;Lo] Scale Low
[`S;hi] Scale High
[`r;Lo] Range Low
[`r;hi] Range High
[`P;EE] Process Error Enable
[`P;EL] Process Error Low
[`FiL] Filter
[`i;er] Error Latching
[`dEC] Display Precision
[`s;ba] Sensor Backup
[`dio]
[`Set]
Digital Input/Output Menu
[```1]
[`dio]
Digital Input/Output 5 (to 6)
[`dir] Direction
[``Fn] Output Function
[``Fi] Function Instance
[`o;Ct] Control
[`o;tb]
Time Base
[`LEu] Active Level
[``Fn] Action Function
[``Fi]
Function Instance
[LiM]
[`Set]
Limit Menu
[```1]
[LiM]
Limit 1
[`L;SD] Sides
[`L;hy] Hysteresis
[SP;Lh]
Set Point Limit High
[SP;LL] Set Point Limit Low
[`L;it] Limit Integrate
[Loop]
[`Set]
Control Loop Menu
[```1]
[Loop]
Control Loop 1
[`h;Ag] Heat Algorithm
[`C;Ag] Cool Algorithm
[t;tUn] Tru-Tune+ ® Enable
[t;bnd] Tru-Tune+ Band
[`t;gn] Gain
[t;Agr] Autotune Aggressiveness
[`P;dl] Peltier Delay
[`UFA] User Failure Action
[FAiL] Input Error Failure
[MAn] Manual Power
[`L;dE] Open Loop Detect Enable
[`L;dt]
Open Loop Detect Time
[`L;dd] Open Loop Detect Deviation
[``rp] Ramp Action
[`r;SC]
Ramp Scale
[`r;rt] Ramp Rate
[`L;SP] Set Point Closed Limit Low
[`h;SP]
Set Point Closed Limit High
[SP;Lo] Set Point Open Limit Low
[SP;hi] Set Point Open Limit High
[otpt]
[`Set]
Output Menu
[```1]
[otpt]
Output 1 (to 4)
[``Fn] Output (2 to 4) Function
[``Fi] Function Instance
[`o;Ct] Control
[`o;tb] Time Base
[`o;Lo] Low Power Scale
[`o;hi] High Power Scale
[``Fn] Output (1) Function
[ss;ti] Soft Start Time
[ALM]
[`Set]
Alarm Menu
[```1]
[ALM]
Alarm 1 (to 2)
[`A;ty] Type
[`sr;a] Source
[`is;a]
Instance
[`A;hy] Hysteresis
[`a;Lg] Logic
[`A;SD] Sides
[`a;LA] Latching
[`A;bL] Blocking
[`a;Si] Silencing
[A;dsp] Display
[`A;dL] Delay
[CUrr]
[`Set]
Current Menu
[```1]
[CUrr]
Current 1 (to 4)
[`C;Sd] Sides
[`C;Ur] Read Enable
[`C;le] Limit Enable
[`C;dt] Detection Threshold
[C;ofs] Heater Current Offset
[`fUn]
[`Set]
Function Key Menu
[```1] to [```2]
[`fUn]
Function Key
[``Fn] Event Function
[``fi]
Function Instance
[gLbL]
[`Set]
Global Menu
[```1]
[gLbl]
Global
[`C_F] Display Units
[AC;LF] AC Line Frequency
[p;typ] Profile Start Type
[`gse]
Guaranteed Soak Enable
[gsd1] Guaranteed Soak Deviation
[d;prs] Display Pairs
[USr;S]
User Settings Save
[USr;r] User Settings Restore
[COM]
[`Set]
Communications Menu
[```1]
[COM]
Communications
[ad;m] Modbus Address
[bAUd]
Baud Rate
[`PAr] Parity
[M;hL] Modbus Word Order
[`C_F] Display Units
[map] Data Map
[`nu;s] Non-Volatile Save
To go to the Setup Page from the
Home Page, press both the Up ¿
and Down ¯ keys for six seconds.
[``Ai]
will appear in the upper
display and [`Set] will appear in
the lower display.
• Press the Up ¿ or Down ¯
key to view available menus.
On the following pages top
level menus are identified with
a yellow background color.
• Press the Advance Key ‰ to
enter the menu of choice.
• If a submenu exists (more than
one instance), press the Up ¿
or Down ¯ key to select and
then press the Advance Key ‰
to enter.
• Press the Up ¿ or Down ¯
key to move through available
menu prompts.
• Press the Infinity Key ˆ to
move backwards through the
levels: parameter to submenu;
submenu to menu; menu to
Home Page.
• Press and hold the Infinity
Key ˆ for two seconds to re-
turn to the Home Page.
