Setup

CAS User’s Guide 61

High Deviation Alarm Output Number

This menu assigns a digital output which activates when the channel is
in high deviation alarm. The digital output only activates if you have set
the high deviation alarm to On.

Selectable values: 1 to 34, None

NOTE

All digital outputs are combined. Therefore, you can assign more
than one alarm to the same output number, and that output will be
On if any of those alarms are On.

Low Deviation Alarm Type

This menu turns off the low deviation alarm or set it to the alarm
function.

Selectable values: Off, Latched, or Unlatched

CHANNEL PROCESS UNITS

CHANNEL NAME ALARM STATUS

01 HI DEV ALARM
OUTPUT ? NONE

CHANNEL PROCESS UNITS

CHANNEL NAME ALARM STATUS

01 LO DEV ALARM
TYPE ? LATCHED
