54 CAS User’s Guide
Setup
Display Format
This menu lets you select a display format for a linear or pulse input.
Choose a format appropriate for your input range and accuracy. (You
will only see the Display Format menu if you are editing a linear or
pulse input.)
The CAS has several available display formats; the display format you
choose determines the default values for the rest of the linear scaling
menus.
High Process Value
From this menu, you can enter a high process value. The high process
value and the high reading value together define one of the points on the
linear scaling function's conversion line.
Selectable Values: The CAS displays the process value based on the
table above.
Display Format Default High PV Default Low PV
-9999 to +30000 10000 0
-999 to +3000 1000 0
-99.9 to +3000.0 1000.0 .0
-99.99 to +300.00 100.00 .00
-9.999 to +30.000 10.000 .000
-.9999 to +3.0000 1.0000 .0000
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
01 DISP FORMAT ?
-999 TO 3000
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
01 INPUT SCALING
HI PV ? 1000
