48 CAS User’s Guide
Setup
Digital Output Polarity
This menu lets you set the polarity of the digital outputs used for alarms.
Selectable values: High or Low
External Alarm Acknowledge Input
An external alarm reset or acknowledge button can be wired to the CAS
at input #8. When activated, it performs the same function as if the
"ALARM ACK" key was pressed.
Selectable values: High or Low
EPROM Information
This view-only display shows the scanner's EPROM version and
checksum.
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
DIG OUT POLARITY
ON ALARM ? HIGH
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
EXTRN ALARM ACK
INPT ACTIVE ? LOW
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
CAS
V 1.00 CS=2233
