FP3000 Series User Manual
4-54
4.4.4
Dimensions
External Dimensions
Unit: mm [in.]
Dimensions with installation fasteners
Unit: mm [in.]
383 [15.08]
60 [2.36]
395 [15.55]
282 [11.10]
294 [11.57]
5 [0.20]
Top
Side
Front
Top
Front
Side
Bottom
Side
2
82[1
1
.10
]
5 [0.20]
60 [2.36]
405 [15.94]
160 [6.30]
165 [6.50]
395 [15.55]
383 [15.08]
160 [6.30]
160 [6.30]
395[15.55]
29
4[1
1
.57]
2
94[1
1
.57]
304
[1
1.97]
237
.5
[9.
3
5
]
