FP3000 Series User Manual
4-14
Dimensions with Cables
Unit: mm [in.]
Installation Fasteners
Unit: mm [in.]
• All the above values are designed in case of cable bending. The dimensions
given here are representative values depending on the type of connection cable
used. Therefore, they are all intended for reference only.
The figure above
shows a DC unit’s
power terminal
Side
Side
Bottom
Rear
317 [12.48]
9[
0.
35
]
16
[0
.6
3]
15[0.59]
25[0.98
]
243
[9
.5
7]
30[1.18]
8.1[0.32]
11
[0
.4
3
]
16 [0.63]
31 [1.22]
M6
∅
10[0.39]
16.6 [0.65]
