FP3000 Series User Manual
9-8
(2)
The cover is fastened at the bottom, and hinges open.
(3)
Loosen the three (3) circuit board attachment screws.
(4)
The circuit board is connected on one side, and hinges open.
• Be sure not to break the rear cover’s four (4) alignment tabs when you open it.
• To prevent FP unit damage, be sure the FP unit's rear cover open/close direction
is correct.
• When the FP unit’s power has just been turned OFF, the circuit board chassis is
still very hot! Be sure to wear gloves to prevent being burned.
Attachment
Screws
