Proface APL3000B - Node Box PC - Manual (Page 29)

PL3000 Series Reference Manual
1-16
„ Backlight Brightness Adjustment: BlBright.cpl
Backlight brightness can be set to one of four levels: Level 0, Level 1, Level 2 or Level 3.
Brightness level 0: Very dark
Brightness level 1: Somewhat dark
Brightness level 2: Somewhat bright
Brightness level 3: Very bright
To use this program when you use Windows
®
2000, click the [Backlight Brightness] icon of the [Control
Panel], when using Windows
®
XP click the [Backlight Brightness] icon of the [Control Panel]’s [Appearance
and Themes]. The default setting is Brightness level 3.
„ Keyboard Emulator: Keyclick.exe
This program allows the User’s mouse operation to perform keyboard-like data input. When this program is
executed on Windows
®
, a keyboard is displayed on the screen of the PL unit.
This is a software keyboard provided by IN-flNITY soft (KeyClick32). Be sure to read the license agreement
in the Appendix before use.
„ API-DLL
These dynamic link libraries allow users to access RAS features that operates on the PL via custom-made
applications. The following two types are available.
For details, refer to the API Reference Manual which can be downloaded from the Pro-face support site “Ota-
suke Pro!” (URL http://www.pro-face.com/otasuke/).
‹ RAS Features: Ioctl.dll
This dynamic link library allows users to access RAS features that operates on the PL via custom-made PL
applications.
‹ Shared Memory Access: Smonras.dll
This dynamic link library allows users to access shared memory via remote RAS features.
SEE Appendices 4 License Agreement (pageA-6)
• Certain application programs may not support this keyboard emulator. Test each application
individually to check if the keyboard emulator will operate correctly.
• This program cannot be used to enter Windows
®
startup screen User Name and Password
information.
• To change the Keyclick program’s font size a keyboard is required.
