LT3000 Series Hardware Manual
2-20
„ Display Specifications
„ Touch Panel Specifications
Model
LT-3300L
LT-3301L
LT-3300S LT-3300T
Display Type Monochrome LCD STN Color LCD TFT Color LCD
Resolution W320 x H240 pixels
Dot pitch W0.36mm [0.01in] x H0.36mm [0.01in]
Effective Display
Area
W115.2mm [4.54in] x H86.4mm [3.40in]
Color/Shade level
Black and White (16
Shades)
(3-Speed Blink)
4096 Colors
(3-Speed Blink)
65,536 Colors
(No 3-Speed Blink)/
16,384 Colors
(3-Speed Blink)
Backlight
White LED
(Not user replaceable.
When replacement is required, contact your local LT distributor.)
Brightness control 8 levels of adjustment available via touch panel
Contrast Adjustment 8 levels of adjustment available via touch panel -
Display Service Life
MTBF value: 50,000hrs. (TYP)
(Backlight display service life is not included.)
Backlight Service
Life 50,000hrs. or more (at 25°C and continuous operation - period until
backlight brightness decreases to 50%)
Language Fonts
Japanese: 6962 (JIS Standards 1 & 2)
(including 607 non-kanji characters)
ANK: 158 (Korean, Traditional Chinese
and Simplified Chinese fonts are downloadable.)
Te
xt composition
Character Sizes
Standard font: 8X8, 8X16, 16X16 and 32X32 dot fonts
Stroke font: 6 to 127dot fonts
Font Sizes
Standard font: Width can be expanded up to 8 times.
Height can be expanded up to 8 times
*1
*1 Font sizes other than those above can be set up by software.
Te
xt
8 x 8 dots 40 Char. x 30 rows
8 x 16 dots 40 Char. x 15 rows
16 x 16 dots 20 Char. x15 rows
32 x 32 dots 10 Char. x 7 rows
Type Resistive Film (analog)
Resolution 1024 x 1024
Service Life 1,000,000 times or more
