NOVA-PV-D5251/D4251 5.25" SBC
Page 43
Pin Description Pin Description
A47 AD11 B47 AD12
A48 GND B48 AD10
A49 AD9 B49 GND
A52 C/BE0 B52 AD8
A53 +3.3 V B53 AD7
A54 AD6 B54 +3.3 V
A55 AD4 B55 AD5
A56 GND B56 AD3
A57 AD2 B57 GND
A68 AD0 B68 AD1
A59 +5 V B59 +5 V
A60 REQ64 B60 ACK64
A61 +5 V B61 +5 V
A62 +5 V B62 +5 V
Table 3-18: PCI Slot
3.2.18 PCIe Mini Card Slots
CN Label: MINI-PCIE1, MINI-PCIE2
CN Type: PCIe Mini card slot
CN Location: See
6
Figure 3-20
CN Pinouts: See Table 3-19
The PCIe Mini card slot is for installing PCIe Mini expansion cards. The MINI-PCIE1 is for
installing IEI Mini DOM.
