NOVA-PV-D5251/D4251 5.25" SBC
Page 40
Pin Row A Row B Row C Row D
5 GND AD9 AD8 GND
6 AD11 VIO2 AD10 M66EN
7 AD14 AD13 GND AD12
8 +3V CBE1- AD15 +3V
9 SERR- GND SBO- PAR
10 GND PERR- +3V SDONE
11 STOP- +3V LOCK- GND
12 +3V TRDY- GND DEVSEL-
13 FRAME- GND IRDY- +3V
14 GND AD16 +3V CBE2-
15 AD18 +3V AD17 GND
16 AD21 AD20 GND AD19
17 +3V AD23 AD22 +3V
18 IDSEL0 GND IDSEL1- IDSEL2
19 AD24 CBE3- VIO4 IDSEL3
20 GND AD26 AD25 GND
21 AD29 +5V AD28 AD27
22 +5V AD30 GND AD31
23 REQ0- GND REQ1- VIO5
24 GND REQ2- +5V GNT0-
25 GNT1- VIO3 GNT2- GND
26 +5V PCICLK0 GND PCICLK1
27 PCICLK2 +5V PCICLK3 GND
28 GND INTD- +5V PCIRST-
29 +12V INTA- INTB- INTC-
30 -12V RESERVED2 RESERVED3 GND
Table 3-17: PCI-104 Connector Pinouts
3.2.17 PCI Slot
CN Label: PCI1
CN Type: PCI Slot
