NANO-QM770 EPIC SBC
Page 8
USB Ports Two USB 2.0 (via pin header)
Four external USB 3.0 ports
SMBus One 4-pin wafer connector
Storage
SATA Two independent SATA channels with 6Gb/s data transfer rates
Environmental and Power Specifications
Power Supply 12V only, AT/ATX support
Power Connector 1 x Internal 4-pin (2x2) power connector
Power Consumption [email protected] (2.30GHz Intel® Core™ i7-3610QE CPU with 4GB
1333MHz DDR3 memory)
Operating Temperature -10ºC ~ 60ºC
Storage Temperature -20ºC ~ 70ºC
Operating Humidity 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions 115 mm x 165 mm
Weight GW/NW 850 g/350 g
Table 1-1: Technical Specifications
