NANO-QM770 EPIC SBC
Page 87
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Chipset
System Agent Bridge Name IvyBridge
System Agent RC Version 1.1.0.0
VT-d Capability Supported
VT-d
[Enabled]
> Graphics Configuration
> Memory Configuration
Enabled to reduce power
consumption in system
off state.
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4 Save
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 20: System Agent (SA) Configuration
Î VT-d [Enabled]
Use the VT-d option to enable or disable VT-d support.
Î
Disabled Disables VT-d support.
Î
Enabled D EFAULT Enables VT-d support.
5.4.2.1 Graphics Configuration
Use the Graphics Configuration menu to configure the video device connected to the
system.
