NANO-QM770 EPIC SBC
Page 7
1.7 Technical Specifications
NANO-QM770 technical specifications are listed in Table 1-1.
Specification NANO-QM770
Form Factor EPIC
CPU Socket Socket G2
CPU 3
rd
generation 22nm Intel® mobile CPU
System Chipset Intel® QM77
Memory One 204-pin 1600/1333/1066 MHz DDR3 SO-DIMM supported
(system max. 8GB)
Graphics Engine Intel® Gen 7 with DirectX 11, OGL 3.1, OCL 1.1
BIOS UEFI BIOS
Digital I/O 8-bit, 4-bit input/4-bit output
Ethernet Controllers Intel® 82579 PHY with Intel® AMT 8.0 support (LAN1)
Intel® 82583V PCIe Ethernet controller
Audio Realtek ALC662 HD Audio codec
Super I/O Controller Fintek F81866
Watchdog Timer Software programmable supports 1~255 sec. system reset
Expansion 1 x Full-size PCIe Mini slot supports mSATA SSD
I/O Interface Connectors
Display Output Ports
(Triple Display
Supported)
1 x DVI-I with analog CRT and DVI support
2 x HDMI (1080p)
Dual-channel 24-bit LVDS, resolution up to 1600x1200
Fan connector One 4-pin wafer for CPU fan
One 3-pin wafer for system fan
Keyboard/Mouse One internal 6-pin wafer connector
Serial Ports Two RS-232 COM connectors (10-pin header)
One RS-422/485 COM connector (4-pin wafer)
