IMBA-C2260-i2 ATX Motherboard
Page 39
Figure 3-23: PCIe x4 Slot Locations
3.2.23 PCI Express x16 Slot
CN Label: PCIEX16_1
CN Type: PCIe x16 slot
CN Location: See Figure 3-24
NOTE:
The PCIe x16 interface setup is made through the BIOS menu in
“Chipset Æ PCH-IO Configuration”. Use the PEG port configuration
BIOS option to configure the PCIe x16 channel mode. Please refer to
Section 5.4.1 for detailed information.
The PCIe x16 expansion card slot is for PCIe x16 expansion card.
