IMBA-C2260-i2 ATX Motherboard
Page 8
Specification/Model IMBA-C2260-i2
Display Output
One VGA (up to 1920 x 1200, 60 Hz)
One iDP interface for HDMI, LVDS, VGA, DVI and DisplayPort (up to
3840 x 2160, 60 Hz)
Ethernet Two RJ-45 GbE ports
Fan
One 4-pin CPU fan connector
One 3-pin system fan connector
Front Panel
One 14-pin header (power LED, HDD LED, IPMI LED, speaker, power
button, reset button)
I
2
C One 4-pin wafer connector
IPMI 2.0 One iRIS module slot
Keyboard and Mouse
One PS/2 keyboard/mouse connector
One internal keyboard and mouse connector (6-pin wafer)
LAN LED Two 2-pin headers for LAN1 LED and LAN2 LED
Parallel Port One parallel port via internal 26-pin box header
Serial ATA Six SATA 6Gb/s connectors (support RAID 0, 1, 5, 10)
Serial Ports
One external RS-232 serial port
Four RS-232 via internal box header
One RS-422/485 via internal 4-pin wafer connector
SMBus One 4-pin wafer connector
TPM One via 20-pin header
USB Ports
Four USB 3.0 ports on rear panel
Four USB 2.0 ports on rear panel
Four internal USB 2.0 ports by pin headers
Environmental and Power Specifications
Power Supply ATX power supply
Power Consumption
[email protected], [email protected], [email protected], [email protected], [email protected]
(3.1 GHz Intel® CPU with four 2 GB 1333 MHz DDR3 memory)
