Î Power Saving Function(ERP) [Disabled]
Use the Power Saving Function(ERP) BIOS option to enable or disable the power
saving function.
Î
Disabled D
EFAULT
Power saving function is disabled.
Î
Enabled
Power saving function is enabled. It will reduce power
consumption when the system is off.
Î PEG port configuration [1 x16 PCIE]
Use the PEG port configuraiton BIOS option to configure the channel mode for the PCIe
x16 slot. When setting to 1 x16 PCIE option, the PCIEX4_2 and PCIEX4_3 slots will be
disabled.
Î
1 x16 PCIE
D
EFAULT
Sets the PCIe x16 slot as one PCIe x16
Î
2 x8 PCIE
Sets the PCIe x16 slot as two PCIe x8
Î
1 x8, 2 x4 PCIE
Sets the PCIe x16 slot as one PCIe x8 or two PCIe x4
Î USB Power SW1 [+5V DUAL]
Use the USB Power SW1 BIOS option to configure the USB power source for the
corresponding USB connectors (Table 5-2).
Î
+5V
Sets the USB power source to +5V
Î
+5V DUAL
D
EFAULT
Sets the USB power source to +5V dual
Î USB Power SW2 [+5V DUAL]
Use the USB Power SW2 BIOS option to configure the USB power source for the
corresponding USB connectors (Table 5-2).
Î
+5V
Sets the USB power source to +5V
Î
+5V DUAL
D
EFAULT
Sets the USB power source to +5V dual
