5.4.1 PCH-IO Configuration
Use the PCH-IO Configuration menu (BIOS Menu 19) to configure the PCH parameters.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
Auto Power Button Status [Disabled (ATX)]
Restore AC Power Loss [Last State]
> PCI Express Configuration
Azalia Configuration
Azalia (HD Audio) [Enabled]
Power Saving Function(ERP)
[Disabled]
PEG port configuration
[1 x8, 2 x4 PCIE]
USB Power SW1 [+5V DUAL]
USB Power SW2 [+5V DUAL]
Select AC power state
when power is re-applied
after a power failure.
---------------------
ÆÅ: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 19: PCH-IO Configuration
Î Restore AC Power Loss [Last State]
Use the Restore AC Power Loss BIOS option to specify what state the system returns to
if there is a sudden loss of power to the system.
Î
Power Off The system remains turned off
Î
Power On The system turns on
Î
Last State D EFAULT The system returns to its previous state. If it was on, it
turns itself on. If it was off, it remains off.
Î Azalia (HD Audio) [Enabled]
Use the Azalia (HD Audio) option to enable or disable the High Definition Audio
controller.
Î
Disabled The onboard High Definition Audio controller is disabled
Î
Enabled D EFAULT The onboard High Definition Audio controller
automatically detected and enabled
