5.4.1.1.1 PCIEX1_1 and PCEIX4_1
Use the PCIEX1_1 and PCIEX4_1 menus (BIOS Menu 21) to configure the PCIEX1_1
and PCIEX4_1 slot settings.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
PCIe Speed
[Gen1]
Detect Non-Compliance Device
[Enabled]
Select PCI Express port
speed.
---------------------
ÆÅ: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous
Values
F3: Optimized
Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 21: PCIEX1_1 and PCIEX4_1 Configuration Menu
Î PCIe Speed [Gen1]
Use this option to select the support type of the PCI Express slots. The following options
are available:
Auto
Gen1
Default
Gen2
Î Detect Non-Compliance Device [Enabled]
Use the Detect Non-Compliance Device option to enable or disable detecting if a
non-compliance PCI Express device is connected to the PCI Express slot.
Î
Disabled Disables to detect if a non-compliance PCI
Express device is connected to the PCI Express
slot.
Î
Enabled D
EFAULT
Enables to detect if a non-compliance PCI Express
device is connected to the PCI Express slot.
