IMBA-C2260-i2 ATX Motherboard
Page 103
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
PC Health Status
> Smart Fan Mode Configuration
CPU temperature :+40 C
System temperature :+36 C
CPU_FAN1 Speed :3456 RPM
SYS_FAN1 Speed :N/A
CPU_CORE :N/A
+5V
:N/A
+12V :N/A
DDR :N/A
+5VSB :+6.120 V
+3.3V :N/A
+3.3VSB :N/A
VBAT
:N/A
Smart Fan Mode Select
---------------------
ÆÅ: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 14: iWDD H/W Monitor
Î PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
ƒ System Temperatures:
o CPU Temperature
o System Temperature
ƒ Fan Speeds:
o CPU Fan Speed
o System Fan Speed
ƒ Voltages:
o CPU_CORE
o +5V
o +12V
o DDR
o +5VSB
o +3.3V
o +3.3VSB
o VBAT
