IMBA-C2260-i2 ATX Motherboard
Page 17
3.1.2 Peripheral Interface Connectors
The table below lists all the connectors on the board.
Connector Type Label
+12V ATX power connector
4-pin Molex power
connector
CPU12V1
Additional power connector 4-pin connector ATXPWR1
ATX power connector 24-pin connector ATX1
Battery connector Battery holder BAT1
Chassis intrusion connector 2-pin header CHASSIS1
DDR3 DIMM sockets 240-pin socket
CHA_DIMM1,
CHA_DIMM2,
CHB_DIMM1,
CHB_DIMM2
Digital I/O connector 10-pin header DIO1
EC debug connector 18-pin header CN3
Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connectors (system) 3-pin wafer
SYS_FAN1,
SYS_FAN2
Front panel audio connector 10-pin header FRONT-PANEL1
Front panel connector 14-pin header F_PANEL1
I 2 C connector 4-pin wafer CN5
Internal DisplayPort connector 19-pin box header DP1
iRIS module slot iRIS module slot IPMI1
Keyboard and mouse connector 6-pin wafer KB_MS1
LAN1 LED connector 2-pin header LED_LAN1
LAN2 LED connector 2-pin header LED_LAN2
mSATA card slot PCIe Mini slot CN2
Parallel port connector 26-pin box header LPT1
