IMBA-C2260-i2 ATX Motherboard
Page 7
1.6 Technical Specifications
The IMBA-C2260-i2 technical specifications are listed below.
Specification/Model IMBA-C2260-i2
Form Factor ATX
CPU Supported LGA1150 Intel® Xeon® E3, Core™ i3, Pentium® or Celeron® CPU
Chipset Intel® C226
Memory
Four 240-pin 1600/1333 MHz dual-channel ECC/non-ECC unbuffered
DDR3 SDRAM DIMMs support (system max. 32 GB)
Graphics Engine
Intel® HD Graphics Gen 7.5 supports DirectX 11.1, OpenCL 1.2 and
OpenGL 3.2
Full MPEG2, VC1, AVC Decode
Audio Realtek ALC662 HD Audio codec (line-in, line-out, mic-in)
BIOS UEFI BIOS
Ethernet Controllers
LAN1: Intel® I217 PHY with Intel® AMT 9.0 support (LAN1_USB1)
LAN2: Intel® I210 PCIe Ethernet controller (LAN1_USB2)
Super I/O Controller Fintek F81866
Watchdog Timer Software programmable supports 1~255 sec. system reset
Expansions
Two PCI slots
One PCIe x16 slot (with x8 signal)
Two PCIe x4 slots (support PCIe x1)
Two PCIe x1 slots
One mSATA card slot (co-lay SATA port 6)
I/O Interface Connectors
Audio Connectors
Line-in, line-out and mic-in audio jacks on rear panel
One internal front panel audio connector (10-pin header)
Chassis Intrusion One 2-pin header
Digital I/O 8-bit, 4-bit input/4-bit output
