5.4.2.2 NB PCIe Configuration
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
NB PCIe Configuration
PEG0
Not Present
PEG0 – Gen X
[Gen1]
Enable PEG
[Enabled]
Detect Non-compliance Device [Enabled]
Configure PEG0 B0:D1:F0
Gen1-Gen3 (PCIEX16_1
Slot)
----------------------
ÆÅ: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 25: NB PCIe Configuration
Î PEG0 – Gen X [Gen1]
Use the PEG0 – Gen X option to select the support type of the PCI Express (PEG)
controller. The following options are available:
Auto
Gen1
Default
Gen2
Gen3
Î Enable PEG [Enabled]
Use the Enable PEG option to enable or disable the PCI Express (PEG) controller.
Î
Disabled Disables the PCI Express (PEG) controller.
Î
Enabled D
EFAULT
Enables the PCI Express (PEG) controller.
Î
Auto
The PCI Express (PEG) controller is disabled if no
PCI Express devices are connected.
