KINO-CVR-D25502/N26002
P a g e 70

Auto D EFAULT The serial port IO port address and interrupt address
are automatically detected.

IO=2F8h;
IRQ=3
Serial Port I/O port address is 2F8h and the interrupt
address is IRQ3

IO=3F8h;
IRQ=3, 4
Serial Port I/O port address is 3F8h and the interrupt
address is IRQ3, 4

IO=2F8h;
IRQ=3, 4
Serial Port I/O port address is 2F8h and the interrupt
address is IRQ3, 4
5.3.8 F81866 H/W Mo n ito r
The H/W Monitor menu (BIOS Menu 11) shows the operating temperature, fan speeds
and system voltages.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PC Health Status
System Temperature1
:+45 C
System Temperature2 :+35 C
Fan1 Speed :2209 RPM
Fan2 Speed :N/A
V_CORE :+1.072 V
VCC3 :+3.392 V
+1.05V :+1.064 V
VCCSM :+1.408 V
VSB5V :+5.616 V
VCC3V :+3.408 V
VSB3V :+3.816 V
VBAT :+3.088 V
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 11: Hardware Health Configuration
 PC He alth Statu s
The following system parameters and values are shown. The system parameters that are
monitored are:
 System Temperatures:
o System Temperature1
