Before the KINO-945GSE is installed in the system, the jumpers must be set in
accordance with the desired configuration. The jumpers on the KINO-945GSE are listed in
7
Table 5-1.
Description Type Label
ATX control 2-pin header ATXCTL1
Clear CMOS 3-pin header J_CMOS1
CompactFlash® master/slave 2-pin header J_CF1
COM3 RS-232/422/485 selector 6-pin header JP1
LCD panel type selector 8-pin header J_LCD_TYPE1
LCD voltage selector 3-pin header J_VLVDS1
Table 5-1: Jumpers
5.6.1 AT/ATX Selection
Jumper Label: ATXCTL1
Jumper Type: 2-pin header
Jumper Settings: See Table 5-2
Jumper Location: See Figure 5-3
The AT/ATX Power Selection jumper specifies the systems power mode as AT or ATX.
Power Selection jumper settings are shown in Table 5-2.
AT Power Select Description
Short Use AT power
Open Use ATX power Default
Table 5-2: AT/ATX Power Selection Jumper Settings
The location of the AT/ATX Power Selection jumper are shown in Figure 5-3 below.
