KINO-945GSE Motherboard
Page 50
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
11 N/C 12 N/C
13 GROUND 14 GROUND
15 LVDSB_Y0+ 16 LVDSB_Y0-
17 LVDSB_Y1+ 18 LVDSB_Y1-
19 LVDSB_Y2+ 20 LVDSB_Y2-
21 LVDSB_CLK+ 22 LVDSB_CLK-
23 N/C 24 N/C
25 GROUND 26 GROUND
27 VCC_LVDS 28 VCC_LVDS
29 VCC_LVDS 30 VCC_LVDS
Table 4-12: LVDS LCD Port Connector Pinouts
4.2.11 PCIe Mini Card Slot
CN Label: MINI_PCIE1
CN Type: 52-pin Mini PCIe Card Slot
CN Location: See
7
Figure 4-12
CN Pinouts: See Table 4-13
The PCIe mini card slot enables a PCIe mini card expansion module to be connected to
the board. Cards supported include among others wireless LAN (WLAN) cards.
