KINO-945GSE Motherboard
Page 38
Connector Type Label
DVI / VGA combo connector VGA and
DVI connector
VIDEO1
LAN / USB combo connector LAN and
2 x USB
LAN/USB1
LAN/USB2
PS/2 keyboard / mouse connector 2 x PS/2 KBMS1
Serial port connector 2 x DB-9 male COM1
Table 4-2: Rear Panel Connectors
4.2 Internal Peripheral Connectors
Internal peripheral connectors are found on the motherboard and are only accessible
when the motherboard is outside of the chassis. This section has complete descriptions of
all the internal, peripheral connectors on the KINO-945GSE.
4.2.1 ATX Power Connector
CN Label: PWR1
CN Type: 20-pin ATX (2x10)
CN Location: See Figure 4-2
CN Pinouts: See Table 4-3
The ATX connector is connected to an external ATX power supply. Power is provided to
the system, from the power supply through this connector.
