2 external interface panel dimensions – IEI Integration KINO-945GSE v1.07 User Manual
Page 25
KINO-945GSE Motherboard
Page 9
2.1.2 External Interface Panel Dimensions
External peripheral interface connector panel dimensions are shown in
6
Figure 2-2: External Interface Panel Dimensions (mm)
