ROCKY-3786EV CPU Card
Page 86
IDE Master and IDE Slave
When entering setup, BIOS auto detects the presence of IDE devices. The Standard
CMOS Features menu shows the status of the auto detected IDE devices. The following
IDE devices are detected and shown in the Standard CMOS Features menu:
IDE Primary Master
IDE Primary Slave
IDE Secondary Master
IDE Secondary Slave
IDE device configurations are changed or set in the IDE Configuration menu. If an IDE
device is detected, and one of the above listed two BIOS configuration options is selected,
the IDE configuration options shown in Section 0 appear.
Drive A/B [1.44M, 3.5in]
Use the Drive A/B configuration to specify the floppy drive type installed in the system.
The floppy drive configuration options are:
None
360K, 5.25 in.
1.2M, 5.25 in.
720K, 3.5 in.
1.44M, 3.5in (Default)
2.88M, 3.5 in.
Video
Use the Video option to select the CRT screen type the system connects to. The video
configuration options are:
EGA/VGA (Default)
CGA 40
CGA 80
MONO
