MODEL NAME
ROCKY-3786EV CPU Card
Page 71
ROCKY-3786EV always take anti-static precautions in
order to prevent ESD damage to the motherboard and
other electronic components like the CPU and DIMM
modules.
The following components must be installed onto the ROCKY-3786EV or connected to the
ROCKY-3786EV during the installation process.
CPU
CPU cooling kit
DIMM modules
Peripheral device connection
4.3.1 CPU Installation
WARNING:
CPUs are expensive and sensitive components. When
installing the CPU please be careful not to damage it in
anyway. Make sure the CPU is installed properly and
ensure that a heat sink and CPU cooling fan are
properly installed before the ROCKY-3786EV is run.
If a heat sink and cooling fan are not properly installed
both the CPU and the board may be damaged.
To install Socket 370-pin CPU onto the ROCKY-3786EV, follow the steps below:
WARNING:
When handling the CPU, only hold it on the sides. DO
NOT touch the pins at the bottom of the CPU.
