ROCKY-3786EV CPU Card
Page 70
1 x ATA66/100 flat cable
2 x SATA cables
1 x SATA power cable
1 x RS232 cable
1 x USB cable
1 x Keyboard/ PS2 mouse Y cable
1 x Mini jumper pack
1 x QIG (Quick Installation Guide)
1 x Utility CD
If any of these items are missing, please contact the CPU card reseller or vendor and do
not proceed any further with the installation.
4.3 ROCKY-3786EV CPU Card Installation
WARNING:
Never run the motherboard without the appropriate heat
sinks and coolers. Heat sinks and coolers can be
ordered from IEI Technology or purchased separately.
WARNING:
Please note that the installation instructions described in
this manual should be carefully followed in order to
prevent damage to the ROCKY-3786EV components
and injury to the user.
WARNING:
When installing electronic components onto the
