MODEL NAME
ROCKY-3786EV CPU Card
Page 63
3.4.1 Clear CMOS Jumper
Jumper Label: JP1
Jumper Type: 3-pin header
Jumper Settings: See Table 3-28
Jumper Location: See Figure 3-26
If the CPU Card fails to boot due to improper BIOS setting, use this jumper to clear the
CMOS data and reset the system BIOS information. To do this, use the jumper cap to
close pins 2 and 3 for a few seconds then reinstall the jumper clip back to pins 1 and 2.
If the “CMOS Settings Wrong” message displays during the boot up process, the fault may
be corrected by pressing the F1 to enter the CMOS Setup menu. Do one of the
following:
Enter the correct CMOS setting
Load Optimal Defaults
Load Failsafe Defaults.
After having done one of the above, save the changes and exit the CMOS Setup menu.
JP1 CLEAR CMOS
1-2 closed Keep CMOS setup (default)
2-3 closed Clear CMOS setup
Table 3-28: Clear CMOS Jumper Settings
3.4.2 BIOS Protection Selection Jumper
Jumper Label: JP2
Jumper Type: 3-pin header
Jumper Settings: See Table 3-29
