MODEL NAME
ROCKY-3786EV CPU Card
Page 35
3.1.3 Rear Panel Connectors
Table 3-2 lists the rear panel connectors on the ROCKY-3786EV CPU card. Detailed
descriptions of these connectors can be found in Section 3.3.
Connectors Type Label
Audio Line Out connector LINE OUT CN16
10/100Mbps Ethernet connector RJ-45 LAN1
Optional 1Gb Ethernet connector RJ-45 LAN2
Keyboard/Mouse connector PS/2 CN23
VGA connector 15-pin VGA connector CN11
Table 3-2: Peripheral Interface Connectors
3.1.4 Onboard Jumpers
Table 3-3 lists the onboard jumpers. Detailed descriptions of these jumpers can be found
in Section 3.4.
Jumpers Type Label
Clear CMOS Setup 3-pin header JP1
BIOS protection setting 3-pin header JP2
Keyboard power selection 3-pin header JP4
CF mode selection 2-pin header JP3
Table 3-3: Onboard Jumpers
