MODEL NAME
ROCKY-3786EV CPU Card
Page 79
4.5 Rear Panel Connectors
4.5.1 Ethernet Connection
The rear panel RJ-45 connectors can be connected to an external LAN and communicate
with data transfer rates up to 1Gb/s.
4.5.2 Keyboard and Mouse Connection
A PS/2 keyboard and a PS/2 mouse can be connected to the appropriate PS/2 connector
on the rear panel.
4.5.3 VGA Connection
The conventional CRT monitor connector (CN11) is a 15-pin, female D-SUB connector. It
can be connected to an external monitor.
