MODEL NAME
ROCKY-3786EV CPU Card
Page 15
1 x IrDA connector
1 x Keyboard/Mouse connector
1 x LAN LED connector
1 x Multi panel connector
1 x Parallel port connector
2 x SATA connectors
2 x Serial port connectors
2 x USB 1.1 connectors
4 x USB 2.0 connectors (optional)
1 x VGA connector
The ROCKY-3786EV CPU board has the following connectors on the board rear panel:
1 x Audio Line Out connector
2 x RJ-45 Ethernet connectors
1 x Keyboard/Mouse connector
1 x VGA connector
The location of these connectors on the CPU Card can be seen in Figure 3-21. These
connectors are fully described in Chapter 2.
NOTE:
There are no configuration jumpers or connectors on the soldering side.
1.2.2 Technical Specifications
ROCKY-3786EV CPU board technical specifications are listed in Table 1-2. Detailed
descriptions of each specification can be found in Chapter 2.
SPECIFICATION
CPUs Supported Intel
®
Pentium® III, Celeron®, or VIA C3
Chipsets Northbridge: Intel ® 815E
Southbridge: Intel® ICH2
I/O Controller IT8712
