Enter the end point for the expansion by typing the first digit of the 100 millisecond
increment. For example, to select 900ms, press the
[9] key. The screen will be
updated as shown:
Press the
[ENTER]
key.
The graph expansion will be printed along with the tabulated test results. You will
be returned to the “START-UP” menu when printing is finished.
4. PLOT 0 – 200MS
Press the [4] key (PLOT 0 - 200MS) to print the tabulated test results along with the
graphic test results from 0 – 200 milliseconds. The graph and tabulated results will
be printed on the thermal printer. You will be returned to the “START-UP” menu
when printing is finished. A sample expansion graph from 0-200 ms is shown in
Figure 29.
EXPANSION FROM:
900MS
"ENTER" TO CONFIRM
