REV 1 CT-8000 S3 USER’S MANUAL
28
3.2.5. Setting the OPEN Timing Analysis Points
Two analysis points are used to calculate the velocity of the circuit breaker in the OPEN
operation. To configure the OPEN timing analysis points:
a. Start from the “START-UP” menu:
Press the
[4]
key (SETUP).
b. The following screen will be displayed:
Press the [1] key (ANALYSIS POINTS).
c. The following screen will be displayed:
Press the
[1]
key (OPEN TIMING).
d. The following screen will be displayed:
1. PERCENT OF STROKE
Press the [1] key (PERCENT OF STROKE) to set the open analysis point #1 as a
percentage of the total stroke value.
OPEN ANALYSIS PT 1
1.
PERCENT OF STROKE
2. DIST FROM CLOSE
3. CONTACT #1
1. OPEN TIMING
2. CLOSE TIMING
3. PRINT SETTINGS
4. TEST PLANS
1. ANALYSIS POINTS
2. MEASUREMENT UNITS
3. SHOT DESCRIPTION
4. NUMBER OF CHANNELS
5. NEXT PAGE
1. RUN TEST 10/07/13
2. GET RESULTS 11:10:10
3. SAVE/RESTORE
4. SETUP
5. DIAGNOSTICS
