CT-8000 S3 USER’S MANUAL REV 1
43
3.2.11. Configuring the Resister Type Transducer Settings
The CT-8000 S3 provides three resistor type transducer channels. The transducer must be
configured before it can be used with the CT-8000 S3. Up to 9 resistor transducer setups can be
stored in the CT-8000 S3’s Flash EEPROM. When a resistive transducer is used with the CT-8000
S3, it is shown as transducer #1 on the timing report as shown in Figure 18.
Creating a New Resistor Type Transducer Setup
Follow the steps below to create a new resistor type transducer setup:
a. Start from the “START-UP” menu:
Press the [4] key (SETUP).
b. The following screen will be displayed:
Press the
[2]
key (MEASUREMENT UNITS).
c. The following screen will be displayed:
Press the [4] key (RES ENCODER).
SELECT UNITS:
1.
ENGLISH
2. METRIC
3. ROTARY ENCODER
4. RES ENCODER
1. ANALYSIS POINTS
2. MEASUREMENT UNITS
3. SHOT DESCRIPTION
4. NUMBER OF CHANNELS
5. NEXT PAGE
1. RUN TEST 10/08/13
2. GET RESULTS 10:10:10
3. SAVE/RESTORE
4. SETUP
5. DIAGNOSTICS
