REV 1 CT-8000 S3 USER’S MANUAL
48
Printing a Resistor Type Transducer Setup Directory
You can print a directory of the stored resistor type transducer setups on the built-in thermal
printer using the steps below:
a. Start from the “START-UP” menu:
Press the
[4]
key (SETUP).
b. The following screen will be displayed:
Press the [2] key (MEASUREMENT UNITS).
c. The following screen will be displayed:
Press the [4] key (RES ENC).
d. The following screen will be displayed:
Press the [3] key (PRINT SETUP DIR). The setup directory will be printed and you will be
returned to the “START-UP” menu. A sample resistor type transducer setup directory
printout is shown in Figure 17.
RESISTIVE ENCODER:
1.
CREATE NEW SETUP
2. LOAD SETUP
3. PRINT SETUP DIR
SELECT UNITS:
1.
ENGLISH
2. METRIC
3. ROTARY ENCODER
4. RES ENCODER
1. ANALYSIS POINTS
2. MEASUREMENT UNITS
3. SHOT DESCRIPTION
4. NUMBER OF CHANNELS
5. NEXT PAGE
1. RUN TEST 10/08/13
2. GET RESULTS 10:10:10
3. SAVE/RESTORE
4. SETUP
5. DIAGNOSTICS
