WaveJet 300A Series
18
WJ-A-GS-E Rev A
Standard Record Length: 500 kpts/Ch
Standard Capture Time: up to 250 µs at 2 GS/s
(WJ354A/352A/334A/332A/324A/322A); up to 500 µs at 1 GS/s (WJ314A/312A)
Acquisition Processing
Averaging: Up to 256 sweeps
Peak Detect: Period of 1 ns
Trigger System
Trigger Modes: Auto, Normal, Single, Stop
Trigger Types: Edge, Pulse Width, Period, Pulse Count, TV
Trigger Source: Any Channel, Ext (100 mV/div), Ext/10(1 V/div), Line
Trigger Slope: Positive, Negative
Trigger Coupling: AC, DC, LFRej, HFRej
Holdoff by Time: up to 50 s
External Trigger Range: EXT: +/-0.5 V, EXT10: +/-5.0 V
External Trigger Impedance: 1 Mohms +/-1.5% || 16 pF (WJ354A/352A/334A/332A)
1 Mohms +/-1.5% || 20 pF (WJ324A/322A/314A/312A)
Basic Triggers
Edge/Slope: Triggers when the signal meets the slope (positive, negative) and level
condition
SMART Triggers
Pulse Width: 15 ns to 50 s
Period (Interval): 40 ns to 50 s
Pulse Count: Edge trigger with Holdoff between 1 and 9999 events
TV Trigger: NTSC, PAL, Custom
Line: up to 3000
Field: (1, 2, 4, 8)
Documentation and Connectivity
Waveform File Data: Save waveform data to internal reference traces or USB memory
in binary, ASCII or Mathcad formats
Screen Images: Save screen images to USB memory in a variety of formats with white
or black background. Print screen images using the rear USB port and a PictBridge®
compatible printer.
