WaveJet 300A Series
16
WJ-A-GS-E Rev A
Input Impedance:
WJ354A
1 Mohm+/-1.5 % || 16 pF, 50 ohm +/-1.5 %
WJ352A
WJ334A
WJ332A
WJ324A
1 Mohm+/-1.5 % || 20 pF
WJ322A
WJ314A
WJ312A
Input Coupling:
WJ354A
GND, DC1Mohm, AC1Mohm, DC50ohm
WJ352A
WJ334A
WJ332A
WJ324A
GND, DC1Mohm, AC1Mohm
WJ322A
WJ314A
WJ312A
Max Input Range:
WJ354A
+/-400 V
pk
CAT I (1 Mohms), 5 V
rms
(50 ohms)
WJ352A
WJ334A
WJ332A
WJ324A
+/-400 V
pk
CAT I (1 Mohms)
WJ322A
WJ314A
WJ312A
Vertical Resolution: 8-bit
