Page 16
Getting Started Manual
WJ-A-GS-E Rev A
15
SPECIFICATIONS
Vertical System
Bandwidth (-3 dB @ 50 ohms):
WJ354A
500 MHz
WJ352A
WJ334A
350 MHz
WJ332A
WJ324A
200 MHz
WJ322A
WJ314A
100 MHz
WJ312A
Input Channels: 4 (WJ354A/334A/324A/314A); 2 (WJ352A/332A/322A/312A)
Rise Time (typical):
WJ354A
750 ps
WJ352A
WJ334A
1.00 ns
WJ332A
WJ324A
1.75 ns
WJ322A
WJ314A
3.50 ns
WJ312A
Bandwidth Limiters:
WJ354A
20 MHz/100 MHz
WJ352A
WJ334A
WJ332A
WJ324A
20 MHz
WJ322A
WJ314A
WJ312A
