Teledyne LeCroy WaveJet 300A Series Getting Started Guide - Manual (Page 18)

Getting Started Manual
WJ-A-GS-E Rev A
17
Sensitivity:
WJ354A
2 mV/div~10 V/div (1 Mohms), 2 mV/div~2 V/div (50 ohms)
WJ352A
WJ334A
WJ332A
WJ324A
2 mV/div~10 V/div (1 Mohms)
WJ322A
WJ314A
WJ312A
DC Gain Accuracy: +/-(1.5 % + 0.5% of full scale)
Offset Range:
2 mV/div~50 mV/div +/-1 V
50.2m V/div~500m V/div +/-10 V
502 mV/div~10 V/div +/-100 V
Offset Accuracy: +/-(1 % + 0.5% of full scale + 1 mV)
Horizontal System
Timebase Range:
WJ354A
500 ps/div - 50 s/div
WJ352A
WJ334A
1 ns/div - 50 s/div
WJ332A
WJ324A
2 ns/div - 50 s/div
WJ322A
WJ314A
5 ns/div - 50 s/div
WJ312A
Clock Accuracy: 10 ppm
Acquisition System
Single-shot Sampling Rate: 1 GS/s
Sampling Rate -- Equivalent Time Sampling (RIS): 100 GS/s
2 Channel Max.: 2 GS/s (WJ354A/352A/334A/332A/324A/322A); 1 GS/s
(WJ314A/312A)
