Getting Started Manual
922157-00 Rev A 211
Configuring the Remote Control Assistant Event Log
1. Under Remote Control Assistant, touch inside the Log Mode data
entry control. Select Off, Errors Only, or Full Dialog from the pop-up
menu.
2. Export the contents of the event log to an ASCII text file by touching
the Show Remote Control Log button. The Event Logs pop-up is
shown. Touch inside the DestFilename data entry control and
provide a file name using your preferred input control method.
Additional information on using the touch screen controls can be
found in the Dialog Area (on page 87).
Then, touch the Export to Text File button.
Printing and Hardcopy Functions
Your instrument provides the ability to output files to printers or plotters
print to file, or e-mail your files. Any Microsoft Windows® supported
printer is supported by your instrument.
Printer Setup
1. Touch File → Print Setup... on the menu bar.
OR
Press the P
RINT
front panel button. Then, touch the Print Setup...
button on the Print flyout menu.
OR
Touch Utilities → Utilities Setup... and click the Hardcopy tab.
The Utilities Hardcopy dialog opens.
2. On the Hardcopy dialog, touch the Printer icon.
3. Under Colors, touch the Use Print Colors checkbox if you want the
traces printed on a white background.
4. Touch inside the Select Printer control and choose a printer from
the pop-up menu.
5. Touch the Properties button to see your printer setup.
