The Actions Dialog
Various configurations can be made to all or some of your Pass/Fail
conditions using the Actions dialog.
By touching the Stop Testcheckbox in the Actions dialog, you can set up
the test to end after a predetermined number of sweeps that you decide.
You can also decide the actions to occur upon your waveforms' passing or
failing, by selecting one or all of the following:

stop

audible alarm

print image of display

emit pulse (if available)

save waveform
The Pulse checkbox (shown right) causes a pulse to be
output through the Aux Out connector at the front of
the oscilloscope.
This pulse can be used to trigger another oscilloscope. You can set the
amplitude and width of the pulse as described in Auxiliary Output Signals.
