Getting Started Manual
922157-00 Rev A 185
Math
Math Traces and Functions Overview
Teledyne LeCroy offers a deep toolset of math functions always growing
and changing to provide superior functionality.
NOTE: To find out which math tools are available in each optional package or for
any detailed explanations about specific functionality, check specifications
regularly maintained on the Teledyne LeCroy website at teledynelecroy.com.
The extreme power of Teledyne LeCroy's math functions is most evident
when used:

to perform mathematical functions on waveforms displayed on any
channel Cx.

to perform mathematical functions on waveforms recalled from
memory Mx.

as a source input waveform Fx in order to perform computations in
sequence.

as parameters Px.
Instruments offering more than one math trace provide even more
enhanced capabilities. For example:

setting up Trace F1 as the difference between Channels 1 and 2

having trace F2 provide the average of F1

having trace F3 provide the integral of F2

go even further and display the integral of the averaged difference
between Channels 1 and 2.
