4. Position T

able Settings

(8) Zone

+/–

x This field defines the range within which the zone output signal turns ON during operation

of solenoid valve mode 1.
To increase flexibility, a different range can be set for each target position.

[Setting example]

Position Zone

Zone

– Comment

[mm] [mm]

[mm]

Rear end

Front end

Intermediate point

Move command to the rear end

Move command to the front end

Move command to the

intermediate point

Zone output signal

Rear end

Front end

Intermediate

point

Home

+ side

limit
