Page 44
32
3. Installation and W
iring
3.11 Connecting the Communication Cable
Connect the communication cable to the SIO connector.
Brown
Yellow
Red
Orange
Blue
Green
Shorting wire UL1004AWG28 (Black)
Yellow
Orange
Brown/Green
Black
Red/Blue
Black
Shield
Pin layout of cable-end connector
RS485 conversion adapter end
Controller end
Cable color
Signal
abbreviation
Pin No.
Cable color
Signal
abbreviation
Pin No.
Not connected to the shield.
