30
3. Installation and W
iring
(3) RCA2 monitor/encoder integrated cable
Model: CB-A &603$ƑƑƑ
( ƑƑƑLQGicates the cable length L. Example: 080 = 8 m)
Red
Yellow
Black
Cable name Pin No. Pin No.
Housing
Contact
Cable name Pin No. Description
Housing: PHDR-18VR (J.S.T. Mfg.)
Contact: SPHD-001T-P0.5 (J.S.T. Mfg.)
Housing: D-1100D1-1827863-1 (AMP)
Contact: D-1 1827570-2
Controller end
Actuator end
Cable model marking
Signal
name
Signal
name
Home check
sensor
Brake power
Encoder phase A
signal
Encoder phase B
signal
Encoder phase Z
signal
Encoder control signal
Encoder power
supply
Shield
Pink (Red z )
Pink (Blue z )
Yellow (Red z )
Yellow (Blue z )
White (Red z )
White (Blue z )
Orange (Red z )
Orange (Blue z )
Grey (Red z )
Grey (Blue z )
Orange (Red z
continuous)
Orange (Blue z
continuous)
Grey (Red z
continuous)
Grey (Blue z
continuous)
Shield
(F
12
)
